What Chipset Is Samsung Exynos 1480 Equivalent To?

What Chipset Is Samsung Exynos 1480 Equivalent To?

Samsung Galaxy A55 5G being the first smartphone to use the Samsung Exynos 1480 chipset, then what is this chipset equivalent to?

The Samsung Exynos 1480 contains eight CPU processors that have four Cortex A78 cores (2.75 GHz) and a Cortex A55 unit (2GHz).

In addition, it is also supported by the Xclipse 530 graphics processor (GPU) which has a power of 1,300 MHz.

This chipset is an Exynos midrange chipset that uses a GPU with AMD RDNA architecture.

Usually, the Samsung Exynos 1480 is paired with internal memory up to UFS 3.1 and RAM reaching LPDDR5 at a frequency of 3,200 MHz.

In this article will discuss about Samsung Exynos 1480 equivalent to what chipset? Come on, watch until the end!

Also read:

• What Chipset is Dimensity 6080 Equivalent to? Let's Find Out Here!
• Let's Find Out What Chipset Exynos 850 is Equivalent to
• MediaTek Chipset Ranking from Lowest to Highest

Samsung Exynos 1480

For those of you who don't know, Samsung Exynos 1480 is chipsets which is embedded in mid-range Android smartphones.

For the CPU, it consists of two clusters, each consisting of four cores, namely four Cortex-A7 power cores (up to 2.75 GHz) and four Cortex-A55 power cores (up to 2.05 GHz).

The chipset is supported by the Xclipse 530 graphics processor (GPU), and also supports Wi-Fi 6E and bluetooth 5.3. Both LPDDR4x and LPDDR5 are connected as RAM and UFS 3.1 as internal memory.

There are massive improvements to this chipset which is made on 4nm fabrication with faster prime core speeds.

The GPU used on the Samsung Exynos 1480 is upgraded to balance the processor's capabilities.

In addition, the screen speed is up to 114 Hz and Full HD+ is used as well as a camera with a resolution of up to 200 MPix.

The specifications of the Samsung Exynos 1480 include the following:

• Chipsets: Exynos 1480 (4nm)
• CPUs: 2x Cortex-A78 2.75GHz, 6x Cortex-A55 2.0GHz
• Memory: LPDDR4X/LPDDR5, UFS 3.1
• Camera: Maximum 200MP, Single-Camera 64MP, Dual-Camera 32+32MP, 4K 60 FPS
• Screen: Maximum FHD+ with 144Hz refresh rate
• GPU: Samsung Xclipse 530

List of Chipsets Equivalent to Samsung Exynos 1480

Below is a list of chipsets that are equivalent to the Samsung Exynos 1480, including:

Qualcomm Snapdragon 865

The Qualcomm Snapdragon 865 chipset is one of the popular flagship chips with similar performance to the Samsung Exynos 1480, which is a mid-range chipset.

The smartphone that uses this chipset is the OPPO Find X2 Pro which achieved an AnTuTu v10 score of 755,040 points.

Meanwhile, for the Samsung Galaxy A55 5G it is 720,068 points. For the Geekbench 6 test results, it achieved a single-core score of 1,239 points and a multi-core score of 3,389 points.

Qualcomm Snapdragon 865 has a 4 + 4 CPU formation, besides that it also presents one prime cluster so that the formation becomes 1 + 3 + 4.

In addition, there is one Cortex A77 prime core (2.84 GHz), three Cortex A77 performance cores (2.42 GHz) and four Cortex A55 power-saving cores (1.8 GHz).

This chipset is built on 7nm fabrication and has been equipped with the Qualcomm Snapdragon X55 5G RF modem with a maximum speed of 7.5 Gb/s.

MediaTek Dimensity 7200

The smartphone powered by MediaTek Dimensity 7200 is the Vivo V27 5G and iQOO Z9.

The Vivo V27 achieved an AnTuTu v10 score of 714,079 points. While the Geekbench 6 score of both, has a score of 1,179 single-core points and 2,670 multi-core points.

The MediaTek Dimensity 7200 has a similar fabrication to the Samsung Exynos 1480, namely 4 nanometers, so both have equivalent power efficiency.

The Dimensity 7200 processor has a 2 + 6 formation, namely the high-performance Cortex A715 cluster (2.8 GHz) and the power-saving Cortex A510 cluster (2 GHz).

The clock speed is 2.8 GHz. As for graphics, the Mali G610 MP4 on the MediaTek Dimensity 7200 has a low clock speed of 1,130 MHz.

Supports LPDDR5x RAM at a frequency of 6,400 MHz with a bandwidth of up to 51.2 Gb/s and storage is supported up to UFS 3.1 type.

In terms of the screen, this chipset can be paired with a Full HD+ resolution screen at a 144 Hz refresh rate and supports 4K video recording at 60 FPS.

Samsung Exynos 990

Still in the same family as the Exynos 1480, the Samsung Exynos 990 has performance equivalent to the Samsung Exynos 1480.

This chip is specifically for flagships, while the Samsung Exynos 1480 is for mid-range smartphones.

The first smartphone powered by Samsung Exynos 990 is the Samsung Galaxy S20 Series as a popular flagship series in 2020.

The Samsung Galaxy S20 Ultra powered by the Samsung Exynos 990 got an AnTuTu v10 score of 741,206 points.

The Geekbench 6 score for both smartphones is 1,155 single-core points and 3,130 multi-core points for the Galaxy S20 Ultra.

The Samsung Exynos 990 is built on Samsung's 7nm fabrication and has eight processor units containing four Cortex A55 cores (2 GHz), two Cortex A76 cores (2.5 GHz), and two Exynos M5 units (2.73 GHz).

Meanwhile, for the graphics processor itself, it uses Mali G77 MP11.

Huawei Kirin 990 5G

One of Huawei's flagship class chips is the Huawei Kirin 990 5G which debuted on the Huawei Mate 30 Pro and Huawei P40 Pro smartphones.

Huawei P40 Pro achieved an AnTuTu v10 score of 721,782 points. In addition, its Geekbench 6 score reached 971 points on single core and 3,168 on multi core.

The CPU formation is 2 + 2 + 4 with high performance Cortex A76 clusters at frequencies of 2.86 GHz and 2.36 GHz.

Meanwhile, the other cluster is the Cortex A55 efficiency core unit with a power of 1.95 GHz, consisting of four units.

Huawei Kirin 990 5G is built on 7nm fabrication and its graphics processor uses Mali G76 MP16.

Additionally, the Huawei Kirin 990 5G only supports up to LPDDR4x RAM and UFS 3.0 storage.

Apple A12 Bionic

One of Apple's chipsets whose performance is equivalent to the Samsung Exynos 1480 is the Apple A12 Bionic which debuted on the iPhone XR, XS, and XS Max.

It has two high performance processor units called Vortex (2.49 GHz) and four power-saving units called Tempest (1.6 GHz).

This chipset is built with 7nm fabrication and is capable of accommodating 6.9 billion transistor units and supports the Apple G11P GPU which contains four execution units.

The Geekbench 6 test results on the Apple A12 Bionic for the iPhone XS Max are 1,314 points on single core and 3,464 points on multi-core. Meanwhile, the AnTuTu v10 score on the iPhone XS Max achieved a score of 663,289 points.

Advantages of Samsung Exynos 1480

Below are the three main advantages of Samsung's chipset, namely the Samsung Exynos 1480, including the following:

• GPU frequency is higher by ~2.2x.
• Smaller transistor size, namely 4 versus 7 nm.
• Supports higher 16% memory bandwidth of 51.2 versus 44 GB/s.
